Stainless Steel 310/310S Pipes, SS 310 Tubes Supplier, Exporter

Stainless Steel 310 Seamless Pipes, ASTM A312 Seamless Pipe, SS 310S Welded Pipes Tubes, DIN 1.4436 Seamless Pipe, Stainless Steel 310S Seamless Pipe, SS 310 Welded Pipes, 310S Stainless Steel Seamless Pipes Manufacturer in Mumbai,India.

20%
VISION

50%
MISSION

98%
QUALITY

Stainless Steel 310 Seamless Pipe Supplier, SS 310S Welded Pipes Manufacturer, ASTM A312 Seamless Pipe, ASME SA312 SS 310S Welded Pipes, DIN 1.4436 Welded Pipes, Grade 310 Welded Tubes Supplier in Mumbai, India.

Stanley Alloys is the most evolving company in the manufacturing of Stainless Steel 310 Seamless Pipes. We are well known for our superior quality products and accurate timely services. Our every single product is manufactured under the expert’s supervision. We also offer various other stainless grades and their respective pipes and tubes.

Stainless Steel 310S Welded Pipes contains good resistivity towards oxidizing agents in the air up intermitting service by 1035°C as well as 1050°C in continuous services. Alloy 310/ 310S Pipes have no content of molybdenum due to which resistivity against pitting is very less. However, 310/310S Tubes are resistant to sulfidation and Oxidizing as well as carburization.

310 Stainless Steel Pipes are in massive demand with top quality service as well for which we are recognized. Its usage has varied instruments such as Welding Filler Wire, Heat Exchangers, Oil Burner Parts, Annealing Covers, Fire Box Sheets, Furnace Parts, Electrodes, Combustion Tubes, and also used many other instruments as well due to its high increasing demand.

We follow strict rules and regulations while manufacturing all products. ASME SA312 TP 310 Pipe grade is made with a combination of special alloys that offers extreme resistance and endurance. This grade also has high outstanding thermal conductivity.

Specification of Stainless Steel 310/ 310S Pipes/Tubes

Pipe Specifications: ASTM A312, A358 / ASME SA312, SA358

Tube Specifications: ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554

Dimensions: ANSI B36.19, ANSI B36.10

Pipe Outside Diameter: 6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB available Ex-stock, OD Size Steel Tubes available Ex-stock

Tube Outside Diameter: 1/8" OD TO 2"OD 3MM OD TO 38 MM OD

Thickness Range: 1MM TO 3 MM 0.028 TO 0.156 IN, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS

Type: Seamless / ERW / Welded / Capillary Tubes

Form: Round Tube, Square Tube, Rectangular Tube

Length: Single Random, Double Random & Required Length

End: Plain End, Beveled End, Treaded

End Protection: Plastic Caps

Finish: Annealed and Pickled, Polished, Bright Annealed, Cold Drawn

External Coating: 3LPE / 3LPP/ FBE/ DFBE/ PP

Stainless steel 310 Seamless Pipes also has heat resistance which is why it is considered an ideal application for high heat temperatures. The most important feature of these pipes is that they provide excellent stability in high pressure. Stainless steel 310/310s seamless and welded pipes are highly ductile, weldable, workable, and strong. The perfect temperature range for these seamless and welded pipes is 1035°C. Along with 24% of chromium and 19% nickel, these stainless steel 310S seamless and welded pipes also include silicon, manganese, carbon, and phosphorous.

Stainless steel 310 seamless and welded pipes are reinforced with extraordinary qualities such as high tensile and yield strength. Stainless steel 310/310S seamless and welded pipes sizes vary from ½ mm to 100mm. These pipes are 100% weldable and also support heat treatments.

Available Types of Stainless Steel 310/ 310S Pipes/Tubes

Seamless Pipes

ASTM A312 SS 310 Seamless Pipes
310S Stainless Steel Seamless Pipe
ANSI B16.5 SS 310 Seamless Pipe
UNS S31000 Seamless Pipes Supplier
Werkstoff Nr. 1.4841 Seamless Pipes Exporter.

Welded Pipes

ASTM A312 SS 310 Welded Pipes
310S Stainless Steel Welded Pipe
ANSI B36.10 SS 310 Welded Pipe
UNS S31000 SS Welded Pipes Supplier
DIN 1.4841 Welded Pipes Exporter.

Seamless Tubes

ASTM A312 SS 310 Seamless Tubes
310S Stainless Steel Seamless Tube
ASME SA312 SS 310S Seamless Tubes
UNS S31000 SS Seamless Tubes Supplier
Werkstoff Nr. 1.4845 Seamless Tubes Exporter.

Welded Tubes

ASTM A312 SS 310 Welded Tubes
310S Stainless Steel Welded Tubing
ASME SA312 SS 310 Welded Tubes
UNS S31000 SS Welded Tubes Supplier
Werkstoff Nr. 1.4841 Welded Tubes Exporter.

ERW Pipes/Tubes

ASTM A312 SS 310 ERW Pipes
SS 310S ERW Round Tubes
310S Stainless Steel ERW Pipes
SS 310 ERW Pipes Supplier
DIN 1.4845 ERW Tubes Exporter.

EFW Pipes

ASTM A358 SS 310 EFW Pipes
ANSI B36.19 SS 310S EFW Pipes
310S Stainless Steel EFW Pipes
SS UNS S31008 EFW Pipes Supplier
Werkstoff Nr. 1.4845 EFW Pipes Exporter.

Equivalent Grades of Stainless Steel 310/ 310S Pipes & Tubes

Grade	UNS No	Old British		Euronorm		Swedish SS	Japanese JIS
Grade	UNS No	BS	En	No	Name	Swedish SS	Japanese JIS
310	S31000	310S24	-	1.4841	X15CrNi25-20	-	SUS 310
310S	S31008	310S16	-	1.4845	X8CrNi25-21	2361	SUS 310S

Chemical Composition of Stainless Steel 310/ 310S Pipes-Tubes

Grade		C	Mn	Si	P	S	Cr	Mo	Ni	N
310	min. max.	- 0.25	- 2.00	- 1.50	- 0.045	- 0.030	24.0 26.0	-	19.0 22.0	-
310S	min. max.	- 0.08	- 2.00	- 1.50	- 0.045	- 0.030	24.0 26.0	-	19.0 22.0	-

Stainless Steel 310/ 310S Pipes/Tubes Mechanical Properties

Grade	Tensile Strength (MPa) min	Yield Strength 0.2% Proof (MPa) min	Elongation (% in 50mm) min	Hardness
				Rockwell B (HR B) max	Brinell (HB) max
310/ 310S	515	205	40	95	217

Weight Chart of 310 Stainless Steel Pipes

Nominal size [inches]	Outside diameter [inches]	Outside diameter [mm]	Wall thickness [inches]	Wall thickness [mm]	Weight [lb/ft]	Weight [kg/m]
1/8	0.405	10.3	0.095	2.41	0.31	0.47
1/4	0.54	13.7	0.119	3.02	0.54	0.8
1/2	0.84	21.3	0.147	3.73	1.09	1.62
3/4	1.05	26.7	0.154	3.91	1.47	2.2
1	1.315	33.4	0.179	4.55	2.17	3.24
1 1/4	1.66	42.2	0.191	4.85	3	4.47
1 1/2	1.9	48.3	0.2	5.08	3.63	5.41
2	2.375	60.3	0.218	5.54	5.02	7.48
2 1/2	2.875	73	0.276	7.01	7.66	11.41
3	3.5	88.9	0.3	7.62	10.25	15.27
3 1/2	4	101.6	0.318	8.08	12.5	18.63
4	4.5	114.3	0.337	8.56	14.98	22.32
5	5.563	141.3	0.375	9.53	20.78	30.97
6	6.625	168.3	0.432	10.97	28.57	42.56
8	8.625	219.1	0.5	12.7	43.39	64.64
10	10.75	273	0.594	15.09	64.43	96.01
12	12.75	323.8	0.688	17.48	88.63	132.08
14	14	355.6	0.75	19.05	106.13	158.1
16	16	406.4	0.844	21.44	136.61	203.53
18	18	457	0.938	23.83	170.92	254.55
20	20	508	1.031	26.19	208.87	311.17
24	24	610	1.125	30.96	296.58	442.08

Schedule Chart of 310 ERW Pipes

1/8" IPS(.405"O. D.)	3 1/2" IPS( 4.000"O. D.)
SCH 40, 80	SCH 10, 40, 80, 160, XXH
1/4" IPS(.540"O. D.)	4" IPS(4.500"O. D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
3/8" IPS(.675"O. D.)	5" IPS( 5.563"O. D.)
SCH 10, 40, 80	SCH 10, 40, 80, 160, XXH
1/2" IPS(.840"O. D.)	6" IPS(6.625"O. D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
3/4" IPS(1.050"O. D.)	8 ” IPS(8.625"O. D.)
SCH 10, 40, 80, 160, XXH	SCH 5, 10, 40, 80, 120, 160, XXH
1" IPS:(1.315′O. D.)	10" IPS(10.750"O. D.)
SCH 5, 10, 40, 80, 160, XXH	SCH 10, 20, 40, 80 (.500), TRUE 80(.500)
1-1/4" IPS(1.660"O. D.)	12" IPS(12.750"O. D.)
SCH 10, 40, 80, 160, XXH	SCH 10, 20, 40(.375), TRUE40(.406), SCH80(.500)
1-1/2" IPS(1.900"O. D.)	14" IPS(14.000"O. D.)
SCH 10, 40, 80, 160, XXH	SCH10 (.188), SCH40 (.375)
2" IPS(2.375"O. D.)	16" IPS(16.000"O. D.)
SCH 10, 40, 80, 160, XXH	SCH10(.188), SCH40(.375)
2 1/2" IPS(2.875"O. D.)	18" IPS (18.000"O. D.)
SCH 10, 40, 80, 160, XXH	SCH-40 (.375)
3" IPS( 3.500"O. D.)
SCH 5, 10, 40, 80, 160, XXH

310 SS Pipe Pressure Rating Chart

Pipe Size (inches)	Pipe Schedule	Temperature (°F)
Pipe Size (inches)	Pipe Schedule	100	200	300	400	500	600	650	700	750
1"	40	3048	2629	2362	2171	2019	1924	1867	1824	1810
1"	80	4213	3634	3265	3002	2791	2659	2580	2528	2501
1"	160	6140	5296	4759	4375	4068	3876	3761	3684	3646
1.5"	40	2257	1947	1750	1608	1496	1425	1383	1354	1340
1.5"	80	3182	2744	2466	2267	2108	2009	1949	1909	1889
1.5"	160	4619	3984	3580	3291	3060	2916	2829	2772	2743
2"	40	1902	1640	1474	1355	1260	1201	1165	1141	1129
2"	80	2747	2369	2129	1957	1820	1734	1682	1648	1631
2"	160	4499	3880	3486	3205	2980	2840	2755	2699	2671
3"	40	1806	1558	1400	1287	1196	1140	1106	1084	1072
3"	80	2553	2202	1979	1819	1691	1612	1564	1532	1516
3"	160	3840	3312	2976	2736	2544	2424	2352	2304	2280
4"	40	1531	1321	1187	1091	1014	967	938	919	909
4"	80	2213	1909	1715	1577	1466	1397	1355	1328	1314
4"	160	3601	3106	2791	2566	2386	2273	2206	2161	2138
5"	40	1342	1158	1040	956	889	847	822	805	797
5"	80	1981	1709	1535	1411	1312	1250	1213	1189	1176
5"	160	3414	2945	2646	2433	2262	2155	2091	2049	2027
6"	40	1219	1052	945	869	808	770	747	732	724
6"	80	1913	1650	1483	1363	1267	1208	1172	1148	1136
6"	160	3289	2836	2549	2343	2179	2076	2014	1973	1953
8"	40	1073	926	832	765	711	678	657	644	637
8"	80	1692	1459	1311	1205	1121	1068	1036	1015	1005
8"	160	3175	2738	2460	2262	2103	2004	1944	1905	1885
10"	40	974	840	755	694	945	615	596	584	578
10"	80	1609	1388	1247	1147	1066	1016	986	966	956
10"	160	3147	2714	2439	2242	2085	1986	1927	1880	1868

Stainless Steel 310/ 310S Pipes/Tubes Make

Manufacturer of Dalmine Stainless Steel 310/ 310S Pipes

Tubacex Make Stainless Steel TP310/ 310S Tubes Exporter

Nippon Steel & Sumitomo Metal Make Stainless Steel 310/ 310S Seamless Pipes

Sumitomo Make Stainless Steel 310/ 310S Welded Pipes Supplier

Arcelor Mittal Make SS 310/ 310S Plain End Pipes

JFE Steel Corporation Make SS 310/ 310S Seamless Tubes Dealer

Ratnamani Make Stainless Steel 310/ 310S Hollow Pipes

Outokumpu Make Stainless Steel 310/ 310S Pipes Exporter

Welspun Make SS 310/ 310S Large Diameter Pipes/Tubes

V & M Make SS 310/ 310S Electric Fusion Welding pipe

MSL Make SS 310/ 310S Seamless pipe/tube Supplier

Jindal Saw Ltd Make Stainless Steel 310/ 310S Pipes/Tubes
