Stainless Steel 304 Pipes & Tubes Manufacturer

Stainless Steel 304 Seamless Pipes, Stainless Steel Pipe ,ASTM A312 SS 304 Pipes, Stainless Steel 304 Pipe, SS 304 Pipe,Stainless Steel 304 Tube, Stainless Steel Pipe Grade 304, 304 Stainless Steel Pipe, ASTM A312 TP 304 Stainless Steel Pipes, Stainless Steel 304L Tubes Supplier in India.


Stainless Steel 304 Pipe

20%
VISION

50%
MISSION

98%
QUALITY


Stainless Steel Pipe 304, ASTM A312 TP 304 Customized Pipes , 304 Stainless Steel Pipe ,ASME SA312 Welded Pipes distributor, Stainless Steel 304 Tube, Stainless Steel 304 Pipe Price ,SS 304 Pipes manufacture, Stainless Steel 304L Seamless Pipes distributor, ASTM A312 TP 304 LSAW Pipes manufacturer, Stainless Steel 304 Customized Pipe.

Stanley Alloys is the market leader in the production of 304 Stainless Steel Pipe. We are one of the largest manufacturers of Stainless Steel 304, 304L and 304H Pipes and Tubes. We have a rapid delivery system base such that clients have smooth progress in their respective projects.

Stainless Steel 304L Welded Pipes have their identification on that basis clients make the order according to their requirements. Such as its specifications are ASTM A249, ASME SA213, ASME A312, ASTM A269, ASTM A358, ASTM A213, ASME A269, ASME A249, ASTM A312, ASME A358. This grade has a thickness from 0.35 mm to 50 mm. Their types are Seamless and ERW, as well as Fabricated and Welded.

Stainless Steel 304 Pipe is an alloy that is made from the two most solid and tensile elements. Nickel and chromium, these elements are reinforced with properties such as moldability, resistance. They showcase excellent properties in high heat and pressure. They also have numerous unique features, such as scalability and potency.

Stainless Steel Pipe is mostly use in piping application for the transport of Oil, Gas and Water Supply. We manufacture various grade of Stainless Steel Pipes. It's provide long lasting durability and corrosion ressistance. We are among the biggest Supplier and Manufacturer of Stainless Steel Pipe.

Specification of Stainless Steel 304 Pipes & Tubes

Pipe Specifications: ASTM A312, A358 / ASME SA312, SA358

Tube Specifications: ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554

Dimensions: ANSI B36.19, ANSI B36.10

Pipe Outside Diameter: 6.00 mm OD up to 914.4 mm OD, Sizes up to 24" NB available Ex-stock, OD Size Steel Tubes available Ex-stock

Tube Outside Diameter: 1/8" OD TO 2"OD 3MM OD TO 38 MM OD

Thickness Range: 1MM TO 3 MM 0.028 TO 0.156 IN, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS

Type: Seamless / ERW / Welded / Capillary Tubes

Form: Round Tube, Square Tube, Rectangular Tube

Length: Single Random, Double Random & Required Length

End: Plain End, Beveled End, Treaded

End Protection: Plastic Caps

Finish: Annealed and Pickled, Polished, Bright Annealed, Cold Drawn

External Coating: 3LPE / 3LPP/ FBE/ DFBE/ PP

ASME SA312 grade 304 Pipe belongs to the 300 austenitic categories. This grade is exceptionally weldable as it has elements like nickel and chromium, which helps it maintain its strength. 304 grade is highly used in industries such as Petrochemical Industry, Power Plant Industry, Oil and Gas Industry, Aerospace Industry, Chemical Industry, Pharmaceuticals Industry, Energy Industry, Pulp & Paper Industry, Refining Industry, and Food Processing Industry because of its rigidness. This alloy is considered as most potent because of its chemical compositions. The composition used in making SS 304 pipes is highly durable and malleable.

Besides that, Stainless steel 304 Pipe is made with austenitic steel; hence the alloy has excellent stability and strength. The alloy provides excellent resistance from corrosion, oxidation, erosion.

Available Types of Stainless Steel 304 Pipes & Tubes

SS 304/ 304L/ 304H Seamless Pipes

Seamless Pipes

Seamless Pipes

ASTM A312 SS 304 Seamless Pipes
304L Stainless Steel Seamless Pipe
ANSI B36.19 SS 304 Seamless Piping
UNS S30400 Seamless Pipes Supplier
SS 1.4301 Seamless Pipes Exporter.
SS 304/ 304L/ 304H Welded Pipes

Welded Pipes

Welded Pipes

ASTM A312 SS 304 Welded Pipes
304L Stainless Steel Welded Pipe
ANSI B36.10 SS 304H Welded Pipe
UNS S30400 Welded Pipes Supplier
SS 1.4301 Welded Pipes Exporter.
SS 304/ 304L/ 304H Seamless Tubes

Seamless Tubes

Seamless Tubes

ASTM A312 SS 304 Seamless Tubes
304L Stainless Steel Seamless Tubing
ASME SA213 SS 304H Seamless Tubing
UNS S30400 Seamless Tubes Supplier
SS 1.4301 Seamless Tubes Exporter.
SS 304/ 304L/ 304H Welded Tubes

Welded Tubes

Welded Tubes

ASTM A269 SS 304 Welded Tubes
304L Stainless Steel Welded Tubes
ASME SA269 SS 304H Welded Tubing
UNS S30400 Welded Tubes Supplier
SS 1.4301 Welded Tubes Exporter.
SS 304/ 304L/ 304H ERW Pipes/Tubes

ERW Pipes/Tubes

ERW Pipes/Tubes

ASTM A312 SS 304 ERW Pipes
SS 304L ERW Round Tubing
304H Stainless Steel ERW Pipes
UNS S30400 ERW Pipes Supplier
SS 1.4301 ERW Tubes Exporter.
SS 304/ 304L/ 304H EFW Pipes/Tubes

EFW Pipes

EFW Pipes

ASTM A358 SS 304 EFW Pipes
ANSI B36.19 SS 304L EFW Pipes
304H Stainless Steel EFW Pipes
UNS S30400 EFW Pipes Supplier
SS 1.4301 EFW Pipes Exporter.

Equivalent Grades of Stainless Steel 304 Pipes & Tubes

STANDARD UNS WERKSTOFF NR. AFNOR EN JIS BS GOST
SS 304 S30400 1.4301 Z7CN18‐09 X5CrNi18-10 SUS 304 304 08Х18Н10

Grade

UNS No

Old British

Euronorm

Swedish SS

Japanese JIS

BS

En

No

Name

304H

S30409

304S51

-

1.4948

X6CrNi18-11

-

-

304L

S30403

304S11

-

1.4306

X2CrNi19-11

2352

SUS 304L

Chemical Composition of Stainless Steel 304 Pipes & Tubes

Grade C Mn Si P S Cr Mo Ni N
304 0.08 2.0 0.75 0.045 0.030 18.0-20.0 - 8.0-10.5 0.10
304H

0.04

-

-

-

-

18.0

-

8.0

-

0.10

2.0

0.75

0.045

0.030

20.0

10.5

304L

-
0.030

-
2.0

-
0.75

-
0.045

-
0.030

18.0
20.0

-

8.0
12.0

-
0.10

Mechanical Properties of 304 Stainless Steel Pipes

Grade

Tensile Strength (MPa) min Yield Strength 0.2% Proof (MPa) min Elongation (% in 50mm) min Hardness
Rockwell B (HR B) max Brinell (HB) max
304/ 304L/ 304H 515 205 40 92 201

Price list of Stainless Steel 304 Pipes & Tubes

Designation of Diameter Outside Diameter
Diameter SCH 10S
(B) (A) Meter Weight Kg/Mtr Wall Price in Price in
MM Thk INR/MTR INR/KG
1/8 6 10.03 0.027 1.2 94.5 350
1/4 8 13.7 0.049 1.65 147 300
3/8 10 17.2 0.063 1.65 189 300
1/2 15 21.3 1.02 2.11 244.8 240
3/4 20 26.7 1.3 2.11 312 240
1 25 33.4 2.13 2.77 489.9 230
11/4 32 24.2 2.73 2.77 627.9 230
11/2 40 48.3 3.16 2.77 711 225
2 50 60.03 3.99 2.77 897.75 225
21/2 65 73 5.34 3.05 1201.5 225
3 80 88.9 6.56 3.05 1476 225
31/2 90 101.6 7.53 3.05 1807.2 240
4 100 114.3 8.5 3.05 1955 230
5 125 141.3 11.74 3.4 2993.7 255
6 150 168.3 14.04 3.4 3510 250
8 200 219.1 20.077 3.76 5400.02 260
10 250 273.1 28.2 4.19 8460 300
12 300 323.9 36.54 4.57 11692.8 320
14 350 355.6 41.99 4.78 14696.5 350
16 400 406.4 48.07 4.78 18026.25 375

Size Chart of Stainless Steel 304 Seamless Pipe

ASTM A312 SS 304 Pipe OD
mm
Pipe WT
mm
in. Sch Kg/m
13.72 1.65 1/4 10S 0.50
13.72 2.24 1/4 40S 0.64
13.72 3.02 1/4 80S 0.81
17.15 1.65 3/8 10S 0.64
17.15 2.31 3/8 40S 0.86
17.15 3.20 3/8 80S 1.12
21.34 2.11 1/2 10S 1.02
21.34 2.77 1/2 40S 1.29
21.34 3.73 1/2 80S 1.65
26.67 2.11 3/4 10S 1.30
26.67 2.87 3/4 40S 1.71
26.67 3.91 3/4 80S 2.23
33.40 2.77 1 10S 2.13
33.40 3.38 1 40S 2.54
33.40 4.55 1 80S 3.29
33.40 6.352) 1 160 4.30
42.16 2.77 10S 2.73
42.16 3.56 40S 3.44
42.16 4.85 80S 4.53
42.16 6.352) 160 5.69
48.26 2.77 10S 3.16
48.26 3.68 40S 4.11
48.26 5.08 80S 5.49
60.33 2.77 2 10S 3.99
60.33 3.91 2 40S 5.52
60.33 5.54 2 80S 7.60
60.33 8.742) 2 160 11.29
73.03 3.05 10S 5.35
73.03 5.16 40S 8.77
73.03 7.01 80S 11.59
88.90 3.05 3 10S 6.56
88.90 5.49 3 40S 11.47
88.90 7.62 3 80S 15.51
88.90 11.132) 3 160 21.67
101.60 3.05 10S 7.53
101.60 5.74 40S 13.78
101.60 8.08 80S 18.92
114.30 3.05 4 10S 8.50
114.30 6.02 4 40S 16.32
114.30 8.56 4 80S 22.67
114.30 13.492) 4 160 34.05
141.30 6.55 5 40S 22.10
141.30 9.53 5 80S 31.44
141.30 15.882) 5 160 49.87
168.28 3.4 6 10S 14.04
168.28 7.11 6 40S 28.69
168.28 10.97 6 80S 43.21
168.28 14.27 6 120 54.75
168.28 18.262) 6 160 68.59
219.08 8.18 8 40S 43.20
219.08 12.7 8 80S 65.63
219.08 18.23 8 120 91.30
219.08 23.012) 8 160 112.97

Stainless Steel 304/ 304L/ 304H Pipes & Tubes Make

Manufacturer of Dalmine Stainless Steel 304/ 304L/ 304H Pipes
Tubacex Make Stainless Steel TP304/ 304L/ 304H Tubes Exporter
Nippon Steel & Sumitomo Metal Make Stainless Steel 304/ 304L/ 304H Seamless Pipes
Sumitomo Make Stainless Steel 304/ 304L/ 304H Welded Pipes Supplier
Arcelor Mittal Make SS 304/ 304L/ 304H Plain End Pipes
JFE Steel Corporation Make SS 304/ 304L/ 304H Seamless Tubes Dealer
Ratnamani Make Stainless Steel 304/ 304L/ 304H Hollow Pipes
Outokumpu Make Stainless Steel 304/ 304L/ 304H Pipes Exporter
Welspun Make SS 304/ 304L/ 304H Large Diameter Pipes/Tubes
V & M Make SS 304/ 304L/ 304H Electric Fusion Welding pipe
MSL Make SS 304/ 304L/ 304H Seamless pipe/tube Supplier
Jindal Saw Ltd Make Stainless Steel 304/ 304L/ 304H Pipes/Tubes
