Incoloy 800,800H,800HT Sheets, Plates and Coils Supplier

Incoloy 800,800H,800HT Sheets, Incoloy 800HT Cold Rolled Coils, Incoloy Alloy N08810 Coils, ASTM B409 Incoloy 800,800H,800HT HR Sheets and Plate Manufacturer, Incoloy 800,800H,800HT Industrial Sheets, Plates and Coils Supplier in Mumbai India.


Incoloy Sheets, Plates, Coils

20%
VISION

50%
MISSION

98%
QUALITY


Incoloy Alloy 1.4859 Slit Coils, Alloy N08811 Perforated Sheets, Incoloy 2.4858 Shim Sheets, Incoloy 800/800H/800HT/ Strips, Inconel Alloy 800, 800H, 800HT Sheets, Plates, Coils Exporter in India.

Stanley Alloys are a wide range of suppliers, exporters and manufacturers of Inconel 800/800h/800HT Sheet plate coil. Inconel 800, 800H and 800HT are nickel-chromium-iron alloys having good efficiency and outstanding resistance to carburization and oxidation in the presence of elevated temperatures. These nickel alloys come similarly by keeping aside the higher level of carbon which is in alloy 800H, and consist of aluminum and titanium up to 1-2% in alloy 800HT.

Both 800H and 800HT are typically considered as premium alloys to the Inconel 800.Inconel 800 alloy is one of the first alloys, and it is little modified into 800H. This modification is basically for controlling carbon from 0.05-0.10% and optimizing stress rupture properties. Inconel 800HT also forward has improvements combined with titanium and aluminum levels of 1% to ensure access to high temperatures. In addition, both alloys obtain elevated temperatures to produce about a usual grain size of coarser. The nickel alloy combines with both 800H and 800HT. Therefore, it is dual certified.

Specification of Incoloy 800, 800H, 800HT Sheets, Plates, Coils

Specifications : ASTM B409 / ASME SB409, AMS 5877

Dimensions : ASTM, ASME, and API

Incoloy Sheet : thickness range from .008" to .0125"

Incoloy Plate : thickness ranges from .0125" to 5.00"

Size : 15NB to 150NB In

Tempers : Annealed, 1/4, 1/2 Hard,  3/4 Hard, Full Hard

Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.

Form : Coils, Foils, Rolls, Plain Sheet, Strip, Flats, Blank (Circle), Ring (Flange) etc.


APPLICATIONS:

Inconel 800 has applications with temperatures higher than 1100 ° F, whereas 800H and 800HT are usually used at temperatures higher than 1100° F, where resistance against rupture and creep is needed. Alloy 800HT has excellent creep strength at temperatures equal to or above 1290°F (700°C).

Inconel 800HT is applicable for applications that need high surface stability. Alloy 800H and Alloy 800HT used in multiple applications access highly corrosive environments, and high temperatures such as heat treating equipment and are excellent for chemical and petrochemical industries. Inconel 800HT will not become embrittled even with the temperature ranges from 1200-1600° F compared to many other stainless sheets of steel, which become brittle.

Stanley Alloys is well-known for the excellent and premium quality of products, and hence, it has huge demands on behalf of customers. By following, we supply them nationally with standard quality of Inconel 800/800H and 800HT.

Available Types of Incoloy 800, 800H, 800HT, Sheets, Plates and Coils

Incoloy 800, 800H, 800HT,   Sheets

Alloy 800, 800H, 800HT Sheets

Incoloy 800, 800H, 800HT Sheets

Incoloy 800 Cold Rolled Sheets, Alloy 2B Finish Sheet, High Incoloy Alloy 800HT No.1 Mirror Finish Sheets, Incoloy UNS N08 CR Sheets, Alloy N08810 Hot Rolled Sheets, Incoloy Alloy 1.4859 Sheets Supplier, Alloy 1.4958, 1.4876 Sheets Exporter.
Incoloy 800, 800H, 800HT,   Plates

Alloy 800, 800H, 800HT Plates

Incoloy 800, 800H, 800HT Plates

Incoloy 800 Cold Rolled Plates, Alloy 2B Finish Plate, High Incoloy Alloy 800HT No.1 Mirror Finish Plates, Incoloy UNS N08 CR Plates, Alloy N08810 Hot Rolled Plates, Incoloy Alloy 1.4859 Plates Supplier, Alloy 1.4958, 1.4876 Plates Exporter.
Incoloy 800, 800H, 800HT,   Coils

Alloy 800, 800H, 800HT, Coils

Incoloy 800, 800H, 800HT Coils

Incoloy 800 Cold Rolled Coils, Alloy 2B Finish Coil, High Incoloy Alloy 800HT No.1 Mirror Finish Coils, Incoloy UNS N08 CR Coils, Alloy N08810 Hot Rolled Coils, Incoloy Alloy 1.4859 Coils Supplier, Alloy 1.4958, 1.4876 Coils Exporter.

Equivalent Grades of Incoloy 800/800H/800HT Sheets, Plates and Coils

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 800 1.4876 N08800 NCF 800 NA 15 ЭИ670 Z8NC32-21 X10NiCrAlTi32-20 XH32T
Incoloy 800HT 1.4958 / 1.4876 N08810 NCF 800HT NA 15(H) ЭИ670 Z8NC33-21 X5NiCrAlTi31-20 XH32T
Incoloy 800HT 1.4859 / 1.4876 N08811 NCF 800HT NA 15(HT) ЭИ670 - X8NiCrAlTi32-21 XH32T

Chemical Composition of Incoloy 800/800H/800HT Sheets, Plates and Coils

Grade C Mn Si S Cu Fe Ni Cr Al Ti
800 0.10 max 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800HT 0.05 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800HT 0.06 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60ᴬ 0.15 – 0.60ᴬ

Alloy 800 / 800H/800HT Sheets, Plates and Coils Mechanical Properties

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
800 / 800HT / 800HT 7.94 g/cm3 1385 °C (2525 °F) Psi – 75,000 , MPa – 520 Psi – 30,000 , MPa – 205 30 %

Incoloy Alloy 800/ 800H/ 800HT/Sheets, Plates, Coils Make

ThyssenKrupp Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
ThyssenKrupp Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
Baosteel Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
Baosteel Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
Aperam Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
Aperam Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
Posco Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
Posco Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
Outokumpu Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
Outokumpu Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
ArcelorMittal Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
ArcelorMittal Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
Nippon Steel & Sumitomo Metal Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
Nippon Steel & Sumitomo Metal Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
JFE Steel Corporation Make Incoloy 800 / 800H / 800HT /   Sheets, Plates, Coils
JFE Steel Corporation Make Incoloy 800 / 800H / 800HT / Sheets, Plates, Coils
