Incoloy 800/800H/800HT Flanges Supplier

Alloy 800 Flanges, ANSI B16.5 Inconel 800HT Flanges, UNS N08800 Flanges, 800H Alloy Plate Flanges, ASME B16.5 Incoloy Flanges, ASTM B564 Incoloy 800/800H/800HT Flange, Incoloy 1.4876 Flanges, Incoloy Alloy 800 Forged Flange, Incoloy 800 HT Pipe Flange, Incoloy 800,800H,800HT Alloy Flanges Manufacturer in Mumbai India.


Incoloy 800/800H/800HT Flanges

VISION

MISSION

QUALITY


Incoloy 800 Flanges Manufacturers in India, ASTM B564 Incoloy 800H Flanges,Incoloy 800HT Flanges, UNS N08810 Flanges, WERKSTOFF NR. 1.4876 Flanges,ASME SB564 Incoloy 800 SORF Flange Exporter, Incoloy Slip on Flanges, Incoloy 800HT Socket weld Flanges, Incoloy 825 Blind Flanges, Incoloy Weld Neck Flanges, Incoloy Lapped Joint Flanges Supplier in Mumbai India.

Stanley alloys are the popular manufacturers and popular suppliers of Inconel 800, 800H and 800HT flanges. We import and export superior quality products for our valuable clients. Inconel 800, 800H and 800HT flanges approach great resistance to corrosive environments and crevice corrosion. This grade of flanges is made from national and international standard quality. We offer the same product according to customers' required specifications such as wall thickness, sizes, surface finishes, and forms.strength and excellent corrosion resistance.

The production of flanges has become effective with the sincere dedication and efforts from our team and professional experts by ensuring products high quality of alloy and also provides high resistance to acid attacks, usually by sulfuric, phosphoric and nitric acids. We use modern technology and the latest tools that enhanced the production of flanges. For example, the Inconel 800 ring type joint flange is highly resistant to chloride ions stress corrosion cracking. Inconel 800H is the threaded flange whereas, 800HT flange is mainly useful for heat-treating processes.

Inconel 800, 800H, and 800HT flanges also offer many good properties applicable for multiple purposes depending upon suitability. The most excellent properties are high tensile strength, good dimensional accuracy, superior surface finishes, rugged construction, anti-corrosive, flexibility, long service life and reasonable maintenance cost, and, most importantly, high toughness such others.

Specification of Incoloy 800/800H/800HT Pipe Flanges

Specifications: ASTM B564 / ASME SB564

Dimensions : ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.

Standard : ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.

Size :1/2" (15 NB) to 48" (1200NB)

Class / Pressure :150#, 300#, 800#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.

Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)

Grade : 800 / 800H / 800HT UNS (N08800, N08810, N08811, N08825), DIN (1.4876, 1.4958, 1.4859, 2.4858)

APPLICATIONS:

We assure all materials to go through the very strict quality of tests before reaching our respective customers. Those tests consist of - Hardness test, chemical analysis, micro and macro test, flaring test and most significantly control measure for their durability and reliability. Also, the raw material test report, material traceability report, guarantee letter, packaging list, certificate of origin and the commercial invoice, radiography reports, etc.

Inconel 800, 800H and 800HT flanges are used in various industries such as the Automobile Industry, Chemical processing, Agricultural equipment, Pylons and architectural structures, Off-shore industries, In bridge and structural steelworks and also applied in pulp and paper industries and others.

Available Types of Incoloy 800 / 800H / 800HT Flanges

Incoloy Slip on Flanges

Slip on Flanges

Slip on Flanges

ASTM B564 Incoloy Alloy 800 Slip on Flanges, ANSI B16.5 Incoloy Alloy 800H SORF Flanges, Incoloy Alloy 800HT Slip on Flanges Supplier, Incoloy Alloy 825 Slip on Raised Face Flange, Incoloy Alloy 800/800H/800HT Slip on Flanges Exporter.
Incoloy Weld Neck Flanges

Weld Neck Flanges

Weld Neck Flanges

ASTM B564 Incoloy Alloy 800 Weld Neck Flanges, ANSI B16.5 Incoloy Alloy 800H WNRF Flanges, Incoloy Alloy 800HT Weld Neck Flanges Supplier, Incoloy Alloy 825 Weld Neck Raised Face Flange, Incoloy Alloy 800/800H/800HT Weld Neck Flanges Exporter.
Incoloy Socket weld Flanges

Socket weld Flanges

Socket weld Flanges

ASTM B564 Incoloy Alloy 800 Socket weld Flanges, ANSI B16.5 Incoloy Alloy 800H SWRF Flanges, Incoloy Alloy 800HT Socket weld Flanges Supplier, Incoloy Alloy 825 Socket weld Raised Flange, Incoloy Alloy 800/800H/800HT Socket weld Flange Exporter.
Incoloy Threaded Flanges

Threaded Flanges

Threaded Flanges

ASTM B564 Incoloy Alloy 800 Threaded Flanges, ANSI B16.5 Incoloy Alloy 800H Screwed Flanges, Incoloy Alloy 800HT Threaded Flange Supplier, Incoloy 825 Alloy Screwed Flange, Incoloy Alloy 800/800H/800HT Threaded Flanges Exporter.
Incoloy Spectacle Blind Flanges

Spectacle Blind Flanges

Spectacle Blind Flanges

ASTM B564 Incoloy Alloy 800 Spectacle Blind Flanges, ANSI B16.5 Incoloy Alloy 800H Spectacle Blind Flanges, Incoloy Alloy 800HT Spectacle Blind Flange Supplier, Incoloy Alloy 825 Spectacle Blind Flanges, Incoloy Alloy 800/800H/800HT Spectacle Blind Flanges Exporter.
Incoloy Blind Flanges

Blind Flanges

Blind Flanges

ASTM B564 Incoloy Alloy 800 Blind Flanges, ANSI B16.5 Incoloy Alloy 800H BLRF Flanges, Incoloy Alloy 800HT Blind Flanges Supplier, Incoloy Alloy 825 Raised Faced Blind Flanges, Incoloy Alloy 800/800H/800HT Blind Flanges Exporter.
Incoloy Orifice Flanges

Orifice Flanges

Orifice Flanges

ASTM B564 Incoloy Alloy 800 Orifice Flanges, ANSI B16.5 Incoloy Alloy 800H Orifice Flange, Incoloy Alloy 800HT Orifice Flanges Supplier, Incoloy Alloy 825 Orifice Flange, Incoloy Alloy 800/800H/800HT Orifice Flanges Exporter.
Incoloy RTJ Flanges

RTJ Flanges

RTJ Flanges

ASTM B564 Incoloy Alloy 800 RTJ Flanges, ANSI B16.5 Incoloy Alloy 800H Ring Type Joint Flanges, Incoloy Alloy 800HT RTJ Flanges Supplier, Incoloy Alloy Ring Type Joint Flange, Incoloy Alloy 800/800H/800HT RTJ Flange Exporter.
Incoloy Forged Flanges

Forged Flanges

Forged Flanges

ASTM B564 Incoloy Alloy 800 Forged Flanges, ANSI B16.5 Incoloy Alloy 800H Forged Flanges, Incoloy Alloy 800HT Forged Flanges Supplier, Incoloy Alloy Forged Flange, Incoloy Alloy 800/800H/800HT Forged Flanges Exporter.

Equivalent Grades of Incoloy 800 / 800H / 800HT Flanges

STANDARD WERKSTOFF NR. UNS JIS BS GOST AFNOR EN OR
Incoloy 800 1.4876 N08800 NCF 800 NA 15 ЭИ670 Z8NC32-21 X10NiCrAlTi32-20 XH32T
Incoloy 800H 1.4958 / 1.4876 N08810 NCF 800H NA 15(H) ЭИ670 Z8NC33-21 X5NiCrAlTi31-20 XH32T
Incoloy 800HT 1.4859 / 1.4876 N08811 NCF 800HT NA 15(HT) ЭИ670 - X8NiCrAlTi32-21 XH32T

Chemical Composition of Incoloy 800 / 800H / 800HT Flanges

Grade C Mn Si S Cu Fe Ni Cr Al Ti
800 0.10 max 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800H 0.05 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60 0.15 – 0.60
800HT 0.06 – 0.10 1.50 max 1.00 max 0.015 max 0.75 max 39.50 min 30.00 – 35.00 19.00 – 23.00 0.15 – 0.60ᴬ 0.15 – 0.60ᴬ

Mechanical properties of Incoloy 800 / 800H / 800HT Flanges

Element Density Melting Point Tensile Strength Yield Strength (0.2%Offset) Elongation
800 / 800H / 800HT 7.94 g/cm3 1385 °C (2525 °F) Psi – 75,000 , MPa – 520 Psi – 30,000 , MPa – 205 30 %

Incoloy Plate 800 / 800H / 800HT Flanges Make

Saudi Aramco Make Incoloy 800 / 800H /800HT Flanges
QALCO Make Incoloy 800 / 800H /800HT Flanges
SPIE Oil & Gas Services Doha LLC Make Incoloy Alloy 800 / 800H /800HT Flanges
GASCO Make Incoloy 800 / 800H /800HT Pipe Flanges
Descon Engineering Make Incoloy Alloy 800 / 800H /800HT Flanges
ORPIC Make Incoloy Alloy 800 / 800H /800HT Flange
Kuwait National Petroleum Company Make Incoloy Alloy 800 / 800H /800HT Flanges
Bahrain Petroleum Company (Bapco) Make Incoloy Flange
Oman United Engineering Services LLC Make Incoloy Alloy Flanges
Petrofac Make Incoloy Plate Flanges
Peninsular Petrotech Engineering Make Incoloy Alloy Forged Flange
Hidayath Group Make Incoloy Flange
